In the fast-evolving world of surface-mount technology (SMT) and electronics manufacturing, efficient and reliable PCB handling is critical. The SK1301 Series PCB Rack stands out as an industry-leading storage and transportation solution, engineered for durability, adaptability, and electrostatic discharge (ESD) protection. With robust construction, intelligent adjustability, and compliance with international ESD standards, this rack is designed to optimize workflow, protect sensitive components, and enhance productivity in high-demand environments.
Detailed Specifications:
Contour Dimensions (L×W×H): 535 mm × 460 mm × 570 mm
Side Plate Slot Depth: 3.5 mm
Slot Width: 5 mm
Slot Pitch: 10 mm
Adjustable Width Range: 50–390 mm (compatible with various PCB sizes)
PCB Storage Capacity: 50 boards
Adjustment Mechanism: Gear Track and Screw System for precise, secure positioning
Side Plate Configuration: Five pre-assembled pieces for quick setup
Base Material: High-strength metal
Weight: 10.5 kg (sturdy yet portable)
Temperature Resistance:
SK1301: 80°C (ideal for standard PCBs)
SK1301-1: 120°C (suited for high-temperature processes)
Surface Resistance: Dissipative — 1.0×10⁴ Ω to 1.0×10⁹ Ω (ESD-safe)
Product Highlights:
Robust Metal Construction:
Built from high-quality metal, the rack offers exceptional durability and longevity,
capable of withstanding rigorous daily use in industrial settings.
Precise Adjustability:
The innovative gear track and screw adjustment system allows users to easily customize the width from 50 mm to 390 mm,
ensuring compatibility with a wide range of PCB sizes.
Superior ESD Protection:
The dissipative surface resistance range (10⁴–10⁹ Ω) effectively controls static electricity,
safeguarding sensitive electronic components from damage during storage or transport.
High-Temperature Variants:
The SK1301-1 model withstands temperatures up to 120°C,
making it suitable for environments involving elevated temperatures such as post-reflow processes.
Efficient Space Utilization:
With a capacity of 50 boards per rack, it maximizes vertical storage space while keeping PCBs organized and easily accessible.
Easy Assembly:
The five pre-assembled side plates reduce setup time and simplify reconfiguration.
Key Selling Points:
Enhanced Productivity:
Reduces handling time and minimizes PCB damage, leading to smoother operations and fewer rejects.
Versatility:
Compatible with most standard PCB sizes and types, offering flexibility across multiple production stages.
ESD-Safe Design:
Me ANSI/ESD S20.20 and IEC 61340-5-1 standards, essential for modern electronics manufacturing.
Durability:
Engineered for long-term use even in harsh conditions, providing excellent return on investment.
Ergonomic Design:
Lightweight for its size (10.5 kg) and designed for easy mobility within the factory floor.
Applications:
The SK1301 Series is ideal for:
SMT Equipment Integration: Use in pick-and-place machines, reflow ovens, and solder paste printers.
PCB Storage: Organized and safe stacking of boards in warehouses or production lines.
PCB Transportation: Secure movement between assembly stages, testing, or packaging.
Electronic Manufacturing Facilities: Suitable for use in cleanrooms, assembly areas, and inspection stations.
R&D and Prototyping Labs: Offers flexibility for various board sizes during development.
The SK1301 Series PCB Rack is a smart investment for any electronics manufacturer looking to improve efficiency,
protect sensitive components, and adapt quickly to varying production needs. Its combination of rugged design,
flexible adjustability, and reliable ESD protection makes it an indispensable tool for modern SMT and electronic assembly applications.
Explore the SK1301 Series today and elevate your PCB management system to the next level!
