In the fast-evolving world of electronics manufacturing and repair,
proper storage and handling of printed circuit boards (PCBs) are critical to maintaining product integrity and performance.
Introducing the SK1304G ESD Magazine Rack—a state-of-the-art,
fully adjustable storage system designed to protect sensitive electronic components from electrostatic discharge (ESD) and physical damage.
Crafted with precision and built for durability, this magazine rack is an essential tool
for any professional environment where PCB safety and organization are paramount.
Product Overview：
The SK1304G ESD Magazine Rack is a robust and functional storage solution engineered for the secure holding of multiple PCBs.
With a contour size of 355 × 320 × 563 mm (L×W×H), it offers ample space while maintaining a compact footprint.
The rack features an innovative design with five assembled side plates, allowing flexible storage options for PCBs of varying sizes.
Each unit is constructed using high-quality, ESD-safe materials, including conductive PP/PPE, zinc-coated steel, and aluminum alloy,
ensuring long-term reliability and compliance with international ESD standards.
Capable of storing up to 50 PCBs, the rack includes adjustable width settings from 50 mm to 250 mm,
making it adaptable to diverse production or workshop needs.
Its handle and screw adjustment mechanisms enable quick and easy reconfiguration without the need for additional tools.
Capable of storing up to 50 PCBs, the rack includes adjustable width settings from 50 mm to 250 mm,
making it adaptable to diverse production or workshop needs.
Its handle and screw adjustment mechanisms enable quick and easy reconfiguration without the need for additional tools.
Key Features:
Superior ESD Protection
The rack is manufactured with dissipative-type materials boasting a surface resistance range of 1.0×10⁴Ω to 1.0×10⁹Ω,
effectively controlling static electricity and preventing damage to sensitive components.
Temperature Resistance
The standard SK1304G model withstands temperatures up to 80°C,
while the SK1304G-1 variant is rated for 120°C, making both versions suitable for
use in environments involving elevated temperatures during PCB processes.
Customizable Storage Configuration
With side plates featuring slots of 3 mm depth, 5 mm width, and 10 mm pitch,
the rack supports easy insertion and adjustment. This design ensures secure holding and quick access to boards.
Durable Construction
The combination of conductive plastic, corrosion-resistant zinc-coated steel,
and lightweight aluminum alloy offers a perfect balance of strength, conductivity, and ease of handling.
Ergonomic and User-Friendly
The handle adjustment system allows for smooth width changes,
reducing operator fatigue and enhancing workflow efficiency.
Why Choose the SK1304G ESD Magazine Rack?
Enhanced PCB Safety: By mitigating ESD risks, the rack helps reduce failure rates and rework costs.
Space Efficiency: Its modular design maximizes vertical storage space, ideal for crowded production floors or labs.
Versatility: Suitable for a wide range of PCB sizes and types, supporting just-in-time manufacturing and repair operations.
Regulatory Compliance: Meets ANSI/ESD S20.20 and IEC 61340-5-1 standards for ESD protective equipment.
Applications:
This magazine rack is widely applicable in:
Electronics manufacturing facilities
PCB assembly and testing lines
Repair and rework stations
Research and development laboratories
Telecommunications and automotive industries
Why Use Conductive PP/PPE, Zinc-Coated Steel, and Aluminum Alloy?
The material selection for the SK1304G is no accident—it’s a result of meticulous engineering to achieve optimal performance:
Conductive PP/PPE: Provides excellent dissipative properties and structural integrity without generating static.
Zinc-Coated Steel: Offers superior corrosion resistance and mechanical strength, ensuring the rack remains functional under heavy use.
Aluminum Alloy: Contributes to overall lightness and portability without compromising on durability.
Together, these materials create a product that is not only ESD-safe but also resistant to wear, chemicals,
and environmental factors, guaranteeing a long service life even in demanding conditions.
The SK1304G ESD Magazine Rack combines innovative design, high-quality materials,
and practical functionality to deliver an unmatched PCB storage solution.
Whether you are looking to improve your ESD control measures, increase organizational efficiency,
or adapt to varying production needs, this rack offers a reliable and cost-effective answer.
Explore the future of PCB storage—choose SK1304G for performance, safety, and versatility.
